| Specifications | X5036A | X5036B | X5036C |
| Spindle taper | 7:24 ISO50 | 7:24 ISO50 | 7:24 ISO50 |
| Distance between spindle nose and table (mm) | 80-440 | 70-450 | 70-450 |
| Distance between spindle hole center and column surface | 320 | 360 | 360 |
| Spindle speed (r/min) | 60-1700 (12steps) | 60-1700 (12steps) | 60-1700 (12steps) |
| Rotation angle of end milling head | ±45° | ±45° | ±45° |
| Table size (mm) | 1250×360 | 1500×360 | 1600×360 |
| Table travel (X/Y/Z) (mm) | 600/320/360 | 1000/320/380 | 1300/320/380 |
| Table auto feeding speed(X/Y)(mm/min) | 22-555(8step)810(rapid) | 15-370(8step)540(rapid) | 15-370(8step)540(rapid) |
| Vertical motor lifting speed of worktable(mm/min) | 590 | 590 | 590 |
| Number/width/spacing of T-grooves in worktable (mm) | 3/18/80 | 3/18/80 | 3/18/80 |
| Main motor (kw) | 4 | 4 | 5.5 |
| Power of Maneuverable Feed Motor of Workbench (kw) | 0.75 | 0.75 | 0.75 |
| Power of feed motor for lifting platform (kw) | 1.1 | 1.1 | 1.1 |
| Cooling pump motor power (kw) | 0.09 | 0.09 | 0.09 |
| Cooling pump flow rate (L/min) | 25 | 25 | 25 |
| Machine size(mm) | 2220x1790x1980 | 2220x1790x1980 | 2520x1890x2080 |
