Features
It adopts FANUC servo motor, with full pulse control for accurate, precise, and fast positioning. It can be used for functions such as Cs contour axis and rigid tapping.
8 live heads on the Y-axis (4 on the end face and 4 on the side face), and 4 fixed tool holders on the end face. By combining turning and boring tools, it can realize complex workpiece processing such as turning, milling, drilling, and tapping can be completed in one clamping process, which reduces errors and losses caused by secondary processing.
The maximum bar through diameter is Φ 45mm, with a maximum X-axis travel of 550mm and a large number of tools.
SC-46YD can be equipped with an eight-station turret and can also be equipped with a tool arrangement or deep hole drill.
Maximum rotation diameter of the spindle Φ 240mm, capable of processing disc parts.
Optional auxiliary devices such as high-pressure cooling device, oil bath feeder, automatic chip conveyor, etc.
Technical Parameters
Description | Specification |
Spindle speed | 6000 rmp |
Spindle end type | ANSI A2-5 |
X axis servo motor | 1.8KW |
Y axis servo motor | 1.2KW |
Z axis servo motor | 1.8KW |
Live head servo motor | 1.8KW |
FANUC control system | FANUC Oi-TF Plus |
Bed spinning diameter | Φ240mm |
Spindle Through-Hole Diameter | Φ56mm |
Bar Through Diameter | Φ45mm |
Max. processing length | 150mm |
Max. processing diameter (for discs) | Φ150mm |
Distance from spindle center to workbench | 75mm |
X axis travel | 1100mm |
Y axis travel | 240mm |
Z axis travel | 350mm |
X/Z axis rapid feed | 24m/min |
Y axis rapid feed | 24m/min |
X/Y/Z axis repeated positioning accuracy | 0.003mm |
X/Y/Z axis positioning accuracy | 0.005mm |
Live head tool | 12*ER25 |
Live head speed | 3000rpm |
Max. drilling diameter | Φ10mm |
Max. tapping diameter | M8(Steel)/ M810(Copper and aluminum) |
Max. tools installed | 21pcs |
Turret | Eight-station turret |
Machine dimension | 2370×1850×2120mm |
Machine weight | 3500KG |
