SJ ADVANCED SERIES CNC EDM WIRE CUTTING MACHINE

Advance Type CNC EDM Wire Cutting Machine has the characteristics of stable cutting and good cutting smoothness. The equipment is suitable for the processing of precision workpiece and precision die.
Availability:
Quantity:

We provide 6 types of medium speed wire cutting machines? How to choose the wire-cut type you need quickly? Click Here

产品细节1

Electrical  Parameters

Description Unit Specification
Max.Cutting Speed mm²/min 200
Wire Electrode Diameter mm φ0.1~φ0.25
Machining Precision(cutting octagon) mm ≤0.01
Taper/Workpiece Height
*3°/100mm
Power Consumption kw 3
Surface roughness μm single cut Ra<2.0  **Multiple cut Ra<0.8
High pressure water tank
Multi-stage filter system
Control method of wire spool, cooling system

Controlled by the program and the NC panel

Repeating position precision of X,Y-axis μm ±1
Guide rail type
Linear guide rail
Speed regulation of transport wire tube

Converter
Number of control axes
5
Power Supply
AC380  50Hz

*The spinneret should be new and the processing time should not be too long.

**The material of workpiece is Cr12 and the height is less than 100mm.


Equipment Specification:

Description Unit Specification Specification Specification
Model
A320C A400C A500C
Worktable Size (LxW) mm 550x700 570x800 680x900
Worktable Travel (LxW) mm 320x400 400x500 500x630
Max.Workpiece Height mm 250 250 300
Max.Workpiece Weight kg 350 400 500
Machine Dimensions(LxWxH) mm 1750x1250x2050 1850x1420x2100 2050x1600x2150
Machine Weight kg 1600 1900 2200


Accessories

Standard Accessories

l  X/Y-axis servo motor

l  Automatic tightening system

l  Z-axis lift electric drive

l  Linear guide rail(HIWIN)

l  High pressure tank

l  Integrated electric lubrication system of guide rail and lead screw

l  Converter

l  Win7 operating system

l  Integrated control cabinet

l  Ruby spinneret

l  Industrial computer IPC

l  Separating transformer system

l  A set of tools and accessories

l  One-year warranty


Optional Accessories:

l  X/Y-axis stepping motor

l  Regulated power supply

l  Diamond spinneret

l  The color of machine is optional (The color of control cabinet is nonoptional)..

l  Two-year warranty


※ The above configuration and parameters are subject to change without prior notice.
