SWV SERIES LOW SPEED BRASS WIRE CUT EDM MACHINE

Structure Charateristics

• Good thermal balance and high rigidity structure ensure the machining accuracy, and the design of UV axis above the column ensures its stability, which enables precise bevel processing even under high water pressure and high line tension.

• Using ball screw and LM linear slide rail, AC servo motor directly drives ball screw, sensitive servo system can do continuous high-frequency response processing. The high-rigidity transmission system ensures the positioning accuracy of each axis.

• The work surface and working sink made of stainless steel will greatly increase the service life.

• With the 100mm stroke of the UV axis, it can achieve taper cutting of ±21 degrees (100mm Z-axis height with wide-angle nozzle and upper and lower water spray cover with aperture of more than 10mm, DA+DB-15mm)

• To meet the various requirements of different customers, the series is specially designed with different mechanical structures, the SWV1065SL with moving column design can withstand large mold weights.

• The structure design is analyzed with FEA to ensure the rigidity and stability of the overall structure.

Equipment Features

1. New Generation of AWT Devices

With the “EC” tension control technology, the probability of successful threading is close to 100%, and the unmanned operation function can be realized day and night.

Stable hardware structure, with superior electronic loop module control, coupled with the rapid processing of system information, even if disconnected, the system will automatically determine the processing flow and ensure that the set tasks are completed.

2. W5F Controller Features

• This controller adopts the industrial standard IPC586 or above host board.

• The central processing unit (CPU) IS 5X86.

• Dynamic memory (DRAM) is 64M bytes.

• High capacity CF card 128M.

• Support touch screen or mouse.

• Support the six axis (B axis) for 6-axis machining.

• Support CF card reader function, network disk drive function. (Optional)

3. Excellent Power Circuit of The Electric Control Box

The high-speed electrolytic-free AC power supply can effectively inhibit the occurrence of electrolytic corrosion, deterioration and anodizing of the workpiece, reduce the softening layer on the surface of the workpiece, and improve the life of the molds for titanium alloys, tungsten steel and large iron-silicon materials.

Equipment Specification
