Description | Specification |
Friction plate size | Common friction plates |
Processing method | grinding, complete the rough and fine grinding process at one time |
Workpiece clamp | electromagnetic suction cup (round) |
Suction cup size | Ф800mm |
Drive power | 2.2Kw, 380V, 3 phases, 50Hz (or 60Hz) |
Movement mode | continuous |
Speed | 0.583-28.6 r/min (variable frequency speed regulation) |
Surface accuracy | horizontal surface end jump ≤0.05mm |
Productivity | 500-1500 pieces/h (based on workpieces) |
motor power | 7.5W(rough grinding), 5.5KW (fine grinding) |
Motor speed | 2900r/min, 380V, 3 phases, 50Hz (or 60Hz) |
Outer diameter of dust suction port | Ф100mm*3 |
Wind speed of suction port | ≥18m/s (required) |
Wind volume of suction port | ≥0.3 m³/s (required) |
Machine size | 1380×1500×1760 mm (excluding suction pipe) |
Machine weight | 1050kg |
